Brocade Multi-Service IronWare Administration Guide (Supporting R05.6.00) User Manual
Page 77
Multi-Service IronWare Administration Guide
59
53-1003028-02
Bootup time
2
A syslog message showing the required memory versus the available memory is generated,
and a similar warning message is displayed on the Management Module and Interface Module
as shown in the following example.
NOTE
When the system is booted up again, the percent of free memory is discretionary and is only an
estimate.
NOTE
Even if all elements are configured with the maximum allowed value, you may not see the
reversion of system-max values that occur on any given Interface Module.
NOTE
Notifications and traps are sent with the same message.
2. The configuration can be easily accommodated.
In this configuration, the Management Module continues to use the configured system-max
value, and send the same value to the installed Interface Modules.
3. The configuration cannot be accommodated.
If the configured system-max value cannot be used, the Management Module will locate the
elements that can be reverted to a default value. These system-max elements will revert to a
default value, and the following message will display on the console.
WARN: Configured System-max cannot be accommodated. Resetting revertible
elements to default values.
A syslog message is generated, and a similar warning message is displayed on the
Management Module and Interface Module as shown in the following example.
NOTE
Once the system-max have been reverted, a user might not be able to configure any
system-max until configuration for some or all of the revertible system-max elements is
removed using “no system-max” CLI.
Brocade# show log
…
Jan 17 22:55:55:N: WARN: Configured System-max Leaves less than 10 percent Free
Memory Available on MP (162529285 req vs 1625292800 available)
Jan 17 22:55:55:N: WARN: Configured System-max Leaves less than 10 percent Free
Memory Available on LP (162529285 req vs 1625292800 available)
Brocade# show log
…
Jan 17 22:55:55:N: WARN: Configured System-max cannot be accommodated on MP
(1625292801 req vs 1625292800 available). Resetting revertible elements to
default
values.
Jan 17 22:55:55:N: WARN: Configured System-max cannot be accommodated on LP
(1625292801 req vs 1625292800 available). Resetting revertible elements to
default
values.
