Monitoring the status of devices in a VPLS network in a Provider’s Maintenance Domain
6
The show cfm connectivity command, displays connectivity statistics for the remote database. For
the show cfm connectivity command to take effect, CFM should first be enabled in the Protocol
Configuration mode.
Syntax: show cfm connectivity[domain NAME] [ma MA NAME]
The [domain NAME] parameter displays information for a specific domain. By default, all defined
domains are shown.
The [ma NAME] parameter specifies the maintenance association name. By default, all defined
domains are shown.
TABLE 33 Output for show CFM connectivity command
This field... Displays...
Domain The Domain is the network or the part of the network for which faults in connectivity
are displayed.
Level The level is the domain level in the range 0-7. The levels can be:
•
Customer’s MD levels: 0 - 2
•
Provider’s MD levels: 3 - 4
•
Operator’s MD levels: 5 – 7
Maintenance association The maintenance association name.
CCM interval The time interval between two successive Continuity Check messages (CCMs) that
are sent by MEPs in the specified Maintenance Domain.
VLAN ID The VLAN identifier of the maintenance association.
VPLS ID The VPLS identifier of the maintenance association.
Priority The priority of the CCM messages, sent by MEPs, in the range 0-7.
RMEP The remote maintenance end point ID
MAC DIsplays the associated MAC Address.
PORT DIsplays the associated port.
Oper State Defines the state of the port attached to the MEP. Possible values OK and Fail
Age Val Age of the operational state of the port.
Brocade#show cfm connectivity
Domain: VPLS-SP Level: 4
Maintenance association: ma_1
CCM interval: 10
VPLS ID: 1
Priority: 3
RMEP MAC VLAN/VC AGE PORT SLOTMASK
==== ===== ======= ==== ==== ====
4 0000.00e2.d80a 00f00a1 2157 0008
2 0000.00e2.b560 00f00a0 2597 0008
Brocade#show cfm connectivity domain VPLS-SP ma ma_1 rmep-id 2
Domain: VPLS-SP Level: 4
Maintenance association: ma_1 VPLS ID: 1 Priority: 3
CCM interval: 10
RMEP MAC PORT Oper Age CCM RDI Port Intf Intvl Seq
State Val Cnt Status Status Error Error
==== =============== ======= ===== === === ==== ====== ====== ===== =====
2 0000.00e2.b560 00f00a0 OK 26000 2600 N 0 0 N N
