Show commands
7
Displaying NTP associations
Use the show ntp associations command to display detailed association information of the NTP
server or peers.
Brocade# show ntp associations
address ref clock st when poll reach delay offset disp
*~172.19.69.1 172.24.114.33 3 25 64 3 2.89 0.234 39377
~2001:db8::234
INIT 16 - 64 0 0.00 0.000 15937
* synced, # selected, + candidate, - outlayer, x falseticker, ~ configured
TABLE 37 show ntp status command output descriptions
Field..... Description.....
synchronized Indicates the system clock is synchronized to NTP server or
peer.
stratum Indicates the stratum number that this system is operating.
Range 2..15.
reference IPv4 address or first 32 bits of the MD5 hash of the IPv6
address of the peer to which clock is synchronized.
precision Precision of the clock of this system in Hz.
reference time Reference time stamp.
clock offset Offset of clock (in milliseconds) to synchronized peer.
root delay Total delay (in milliseconds) along path to root clock.
root dispersion Dispersion of root path.
peer dispersion Dispersion of root path.
system poll interval Poll interval of the local system.
last update Time the router last updated its NTP information
server mode Status of the NTP server mode for this device.
client mode Status of the NTP client mode for this device.
master Status of the master mode
master stratum Stratum number that will be used by this device when master
is enabled and no upstream time servers are accessible.
panic mode Status of the panic mode. If the clock offset is more than 1000
seconds with the current time, then panic mode will be on.
