314 Multi-Service IronWare Administration Guide
53-1003028-02
CAM partition profiles
9
IP VPN SNet 11: 523456 (07fcc0) - 523471 (07fccf)
IP VPN SNet 12: 523472 (07fcd0) - 523487 (07fcdf)
IP VPN SNet 13: 523488 (07fce0) - 523503 (07fcef)
IP VPN SNet 14: 523504 (07fcf0) - 523519 (07fcff)
IP VPN SNet 15: 523520 (07fd00) - 523535 (07fd0f)
IP VPN SNet 16: 523536 (07fd10) - 523551 (07fd1f)
IP VPN SNet 17: 523552 (07fd20) - 523567 (07fd2f)
IP VPN SNet 18: 523568 (07fd30) - 523583 (07fd3f)
IP VPN SNet 19: 523584 (07fd40) - 523599 (07fd4f)
IP VPN SNet 20: 523600 (07fd50) - 523615 (07fd5f)
IP VPN SNet 21: 523616 (07fd60) - 523631 (07fd6f)
IP VPN SNet 22: 523632 (07fd70) - 523647 (07fd7f)
IP VPN SNet 23: 523648 (07fd80) - 523663 (07fd8f)
IP VPN SNet 24: 523664 (07fd90) - 523679 (07fd9f)
IP VPN SNet 25: 523680 (07fda0) - 523695 (07fdaf)
IP VPN SNet 26: 523696 (07fdb0) - 523711 (07fdbf)
IP VPN SNet 27: 523712 (07fdc0) - 523727 (07fdcf)
IP VPN SNet 28: 523728 (07fdd0) - 523743 (07fddf)
IP VPN SNet 29: 523744 (07fde0) - 523759 (07fdef)
IP VPN SNet 30: 523760 (07fdf0) - 523775 (07fdff)
IP VPN SNet 31: 523776 (07fe00) - 524287 (07ffff)
MAC Section : 524288 (080000) - 655359 (09ffff)
MAC Forwarding: 524288 (080000) - 655317 (09ffd5)
MAC Flooding : 655318 (09ffd6) - 655327 (09ffdf)
Misc Protocol : 655350 (09fff6) - 655381 (0a0015)
Session Section : 655360 (0a0000) - 753663 (0b7fff)
IP Multicast : 655360 (0a0000) - 671743 (0a3fff)
Broadcast ACL : 673792 (0a4800) - 675839 (0a4fff)
Receive ACL : 671744 (0a4000) - 673791 (0a47ff)
Rule-based ACL: 673792 (0a4800) - 753663 (0b7fff)
IPv6 Session Sec: 753664 (0b8000) - 786431 (0bffff)
IP Multicast : 753664 (0b8000) - 770047 (0bbfff)
Receive ACL : 770048 (0bc000) - 770559 (0bc1ff)
Rule-based ACL: 770560 (0bc200) - 786431 (0bffff)
Out Session : 786432 (0c0000) - 983039 (0effff)
Out IPv6 Session: 983040 (0f0000) - 104857 (0fffff)
...
Syntax: show cam-partition
The output displays the CAM partitioning profile name, slot number, number of CAM device, and
total CAM size. It also displays the raw size, user size, and reserved size for each of the CAM
sub-partitions.
The information related to the broadcast ACL CAM partition is shown in bold text in the previous
output.
Table 52 describes the output parameters of the show cam-partition command.
TABLE 52 Output parameters of the show cam-partition command
Field Description
CAM partitioning profile Shows the CAM profile name.
Slot Shows the slot number.
# of CAM device Shows the number of the CAM device.
Total CAM Size Shows the total available CAM size.
