Multi-Service IronWare Administration Guide 89
53-1003028-02
Chapter
3
Telemetry Solutions
Table 21 displays the individual Brocade devices and the Interface Parameters features they
support.
About telemetry solutions
Telemetry Solutions provides a VLAN matching capability for IPv4 and IPv6 ACLs. Telemetry
Solutions also includes new types of PBR next-hop (network interface). You can create policies that
classify network traffic into different categories based on the extended ACLs and forward each
category of traffic differently, based on the configured policy. With Telemetry Solutions, the ACL
match can be based on both VLAN ID and the existing Layer 3 or Layer 4 fields.
Telemetry Solutions improves the user experience with options to classify the network traffic (VLAN
matching) and providing more choices for PBR forwarding. You can also utilize the rule-name field
in the route-map to organize and extract information about PBR configurations.
Limitations
The ACL keyword VLAN is only intended to be used in PBR. For ACLs that contain the VLAN keyword
and is used as standalone ACL, the following restrictions apply:
• An ACL that contains the VLAN keyword cannot be applied to Virtual Interfaces (VEs).
• The VLAN keyword will be ignored and will have no effect if the ACL is:
• applied to a physical interface or LAG interface
• applied to a management interface
• used as an IP receive ACL
• used in ACL-based rate-limiting
• If the set interface command exists in a route-map and the route-map is applied to a interface,
it will only permit packets from the configured VLAN unless the command allow-all-vlan pbr is
also configured on the interface.
TABLE 21 Supported Brocade interface parameter features
Features
supported Brocade
NetIron XMR
Series Brocade
MLX Series Brocade
NetIron CES
2000 Series
BASE
package Brocade
NetIron CES
2000 Series
ME_PREM
package Brocade
NetIron CES
2000 Series
L3_PREM
package Brocade
NetIron CER
2000 Series
Base
package Brocade
NetIron CER
2000 Series
Advanced
Services
package
Telemetry
Solutions Yes Yes No No No No No
