244 Multi-Service IronWare Administration Guide
53-1003028-02
One-way Delay Measurement
6
Syntax: vpls vpls-name id
Syntax: vlan vlan-id
Syntax: tagged ethernet slot/port
CFM Configuration
1. Enable CFM.
Brocade(config)#cfm-enable
Brocade(config-cfm)#
Syntax: cfm-enable
2. Configure the domain.
Brocade(config)#cfm-enable
Brocade(config-cfm)#domain-name md1 level 7
Brocade(config-cfm-md-md1)#
Syntax: domain-name md_name id id level level
3. Configure MA.
Brocade(config-cfm-md-md1)#ma-name ma1 vpls-id 100 priority 4
Brocade(config-cfm-md-md1-ma-ma1)#
Syntax: ma-name ma_name [id id] vlan-id vlan | vpls-id vpls priority priority
Ma_name - Maintenance Association Name
4. Configure MEP.
Brocade(config-cfm-md-md1-ma-ma1)#mep 1 up vlan 100 port ethernet 1/1
Syntax: mep id down | up vlan vlan port ethernet slot/port
One-way delay measurement configuration
NOTE
The following configuration is common for common for VLAN, VPLS, and VLL.
One-way delay measurement initiator session configuration
1. One-way delay measurement initiator session creation
Brocade(config)#cfm
Brocade(config-cfm)# oneway-dm initiator 1
Brocade (config-cfm-oneway-dm-initiator-1)# domain md1 ma ma1 src-mep 1
target-mep 101
Syntax: oneway-dm initiator session-index
session_index - Is used to configure the one-way delay measurement initiator session index
(1-1000)
Syntax: domain md_name ma ma_name src-mep id target-mep id
Md_name - Domain Name
