Multi-Service IronWare Administration Guide

55

53-1003028-02

Configuring CAM size for an IPv4 multicast group

2

Configuring CAM size for an IPv4 multicast group

To configure the CAM size of an IPv4 multicast group, enter the following command.

Brocade(config)# system-max ipv4-mcast-cam

Syntax: [no] system-max [ipv4-mcast-cam]

By default, no system-max parameter is configured.

The ipv4-mcast-cam parameter allows you to specify the maximum CAM size you want for an IPv4
multicast group.

The decimal parameter specifies the range that is supported for configuring the CAM size. On the
Brocade NetIron XMR, the minimum value supported is 0, and the maximum value supported is
65536. The default value is 8192. On the Brocade MLX series, the minimum value supported is 0,
and the maximum value supported is 32768. The default value is 4096.

Upon configuration, the Brocade system will verify the input value with the amount of CAM
resources that are available. If the Brocade system is unable to allocate requested space, it will
display the following error message on the Brocade NetIron XMR and Brocade MLX series.

If there is not enough CAM resources available to change the cam-partition profile from IPv4 to
IPv6, the following message is displayed.

l2-metro-2

0

114688

8192

mpls-l3vpn-2

0

114688

8192

mpls-vpls-2 0

114688

8192

ipv4-ipv6 0

114688

8192

ipv4-vpls

0

114688

8192

ipv4-ipv6-2

0

81920

8192

TABLE 11

System max ifl-cam values available by CAM profile on Brocade NetIron XMR and
Brocade MLX series (Continued)

CAM profile

Minimum value

Maximum value

Default value

Brocade(config)#system-max ipv4-mcast-cam 60000

Error - IPv4 Multicast CAM (60000) exceeding available CAM resources

Total IPv4 ACL CAM: 98304(Raw Size)

IPv4 Receive ACL CAM: 16384(Raw Size)

IPv4 Source Guard CAM: 32(Raw Size)

Reserved IPv4 Rule ACL CAM: 1024(Raw Size)

Available IPv4 Multicast CAM: 80864(Raw Size) 40432(User Size)

Brocade(config)#cam-partition profile ipv4-ipv6

Error - IPv4 Receive ACL CAM (8192) exceeding available CAM resources

Total IPv4 ACL CAM: 98304(Raw Size)

IPv4 Multicast CAM: 120000(Raw Size)

IPv4 Source Guard CAM: 32(Raw Size)

Reserved IPv4 Rule ACL CAM: 1024(Raw Size)

Available IPv4 Receive ACL CAM: 0(Raw Size) 0(User Size)

Error - Failed to select this CAM profile
