Multi-Service IronWare Administration Guide

63

53-1003028-02

Switch fabric fault monitoring

2

Brocade#show sfm-links all

SFM#/FE# | FE link# | LP#/TM# | TM link# | link state

----------+-----------+---------+-----------+---------

2 / 1 | 32 | 3 / 1 | 13 | UP

2 / 1 | 31 | 3 / 2 | 01 | UP

2 / 1 | 11 | 3 / 1 | 01 | UP

2 / 1 | 12 | 3 / 2 | 13 | UP

2 / 3 | 32 | 3 / 1 | 19 | UP

2 / 3 | 31 | 3 / 2 | 07 | UP

2 / 3 | 11 | 3 / 1 | 07 | UP

2 / 3 | 12 | 3 / 2 | 19 | UP

3 / 1 | 32 | 3 / 1 | 16 | UP

3 / 1 | 31 | 3 / 2 | 04 | UP

3 / 1 | 11 | 3 / 1 | 04 | UP

3 / 1 | 12 | 3 / 2 | 16 | UP

3 / 3 | 32 | 3 / 1 | 22 | UP

3 / 3 | 31 | 3 / 2 | 10 | UP

3 / 3 | 11 | 3 / 1 | 10 | UP

3 / 3 | 12 | 3 / 2 | 22 | UP

WARN: LP 3 has 8 links up, less than minimum to guarantee line rate traffic

forwarding

Syntax: show sfm-links sfm-number | all [errors]

The sfm-number variable specifies an SFM that you want to display link information for.

The all option displays link information for all SFMs in the chassis.

The errors option only displays information for SFM links that are in the DOWN state.

The output of this command can also be filtered using an output modifier. To use an output
modifier, type a vertical bar ( | ) followed by a space and one of the following parameters:

begin - begin output with the first matching line

exclude - exclude matching lines from the output

include - include only matching lines in the output

A warning statement is sent if the number of operational links falls below the minimum threshold.
This warning is displayed to warn users that the line rate traffic will not be maintained.

The show sfm-links command displays the following information.

TABLE 16

CLI display of SFM link information

This field...

Displays...

SFM#

The switch fabric module number.

FE#

The FE number.

FE link#

The number of the interconnect between the SFM and the FE.

LP#

The slot number where the Interface module (LP) is installed.

TM#

The number of the traffic manager used in the link.
