52

Multi-Service IronWare Administration Guide

53-1003028-02

Configuring system max values

2

NOTE

Default values are the same irrespective of the software package on the Brocade NetIron CES and
Brocade NetIron CER devices.

NOTE

The maximum FIB scalability for Brocade NetIron CER and Brocade NetIron CES has been tested
using an internet route mix. When using route prefixes concentrated in a narrow prefix length range,
the scalability numbers will be lower. It is important to design your network keeping this in mind.

To configure system-max values, use the following command.

Syntax: [no] system-max config-file-size | gre-tunnels | ip-arp | ip-cache |ip-filter-sys | ip-route |

ip-static-arp | ipv4-mcast-cam | ip-subnet-port | ip-tunnels|vrf| vrf-route | ipv6-cache |
ipv6-mcast-cam | ipv6-route | l2-acl-table-entries |ifl-cam | mac | mgmt-port-acl-size |
subnet-broadcast-acl-cam | receive-cam | rstp | session-limit | spanning-tree |
trunk-num | virtual-interface | vlan | vpls-mac | vpls-num |ecmp-pram-block-size

The gre-tunnels parameter sets the maximum number of GRE tunnels.
For minimum, maximum and default values for this parameter refer to

Table 9

.

TABLE 10

System max values for Brocade NetIron CES, Brocade NetIron CER, and Brocade NetIron CER-RT devices

Parameter

Minimum
value for
Brocade
NetIron
CES

Maximum
value for
Brocade
NetIron CES

Default
value for
Brocade
NetIron
CES

Minimum
value for
Brocade
NetIron
CER

Maximum
value for
Brocade
NetIron CER

Default
value for
Brocade
NetIron
CER

Minimum
value for
Brocade
NetIron
CER-RT

Maximum
value for
Brocade
NetIron
CER-RT

Default
value for
Brocade
NetIron
CER-RT

config-file-size

2097152

16777216

8388608

2097152

16777216

8388608 2097152

16777216 8388608

ip-arp 2048

16384

4096

2048

16384

4096

2048

16384

4096

ip-cache

4096

32768

16384

4096

524288

290816

4096

1572864

290816

ip-filter-sys

1024

32768

4096

1024

32768

4096

1024

32768

4096

ip-route

4096

32768

16384

4096

524288

290816

4096

1572864

290816

ip-subnet-port

24

128

24

24

128

24

24

128

24

l2-acl-table-entries 64

256

64

64

256

64

64

256

64

mac

4000

131072

56320

4000

131072

56320

4000

131072

65536

mgmt-port-acl-size 1

100

20

1

100

20

1

100

20

rstp 1

128

32

1

128

32

1

128

32

session-limit

1024

32768

32768

1024

32768

32768

1024

32768

32768

spanning-tree

1

128

32

1

128

32

1

128

32

virtual-interface 40

1024

255

40

4095

255

40

4095

255

vlan

512

4095

512

2

8192

512

2

8192

512

vrf

1

16

1

1

128

16

1

128

16

ipv6-cache

1024

131072

1024

1024

131072

1024

1024

262141

8192

ipv6-route

1024

131072

1024

1024

131072

8192

1024

262141 8192

vrf-route

1024

32768

1024

1024

32768

1024

1024

1572864

1024

ip-tunnels

32

128

32

32

128

32

32

256

32
