Option Description
Enable LUN and do not configure LUN masking Do not configure LUN masking. Any initiator that is
able to connect to a Fibre Channel port in the port
group will be able to see the LUN.
Keep LUN disabled and configure LUN masking in
the next step
Configure LUN masking. You can restrict which
initiators can see the LUN.
7. Click OK.
8. Optional: Configure LUN masking.
a. Add one or more initiator WWPNs to the LUN's authorized initiators list.
Method Steps
Add from WWPN list 1. Select one or more initiator WWPNs in the
WWPN list.
2. Click Add.
Add WWPNs as text 1. Specify one WWPN per line using any of the
following formats:
• XXXXXXXXXXXXXXXX
• XX:XX:XX:XX:XX:XX:XX:XX
2. Click Add.
b. Optional: Select Add unknown WWPNs to the FC WWPN Aliases List.
When selected, QTS will add any unknown WWPNs to the list of known aliases. To view the list, go
to iSCSI & Fibre Channel > Fibre Channel > FC WWPN Aliases .
c. Optional: Select Enable LUN.
If selected, QTS will enable the LUN after mapping it to the target.
d. Click OK.
Fibre Channel Port Actions
Action Description
Edit Alias Specify an alias for the Fibre Channel port.
The alias must consist of 1 to 20 characters from any
of the following groups:
• Letters: A-Z, a-z
• Numbers: 0-9
• Special characters: Hyphen (-), underscore (_)
View initiators View a list of all Fibre Channel initiators currently
logged into the port.
Edit port binding Modify the port binding for the port. Port binding
allows you to restrict which initiators are allowed to
connect to the port.
For more information, see Fibre Channel Port
Binding .
