Action Description Steps
Recovery QTS periodically takes snapshots of a
VJBOD Cloud volume. You can use these
recovery point snapshots to restore the
volume to a previous state.
For details, see VJBOD Cloud Volume and
LUN Recovery .
LUN Actions
Action Description Steps
Expand LUN Increase the capacity of the LUN or its
stored space.
1. Click Expand LUN.
2. Specify the new capacity of the LUN
or its stored space, in GB.
3. Optional:
Click Set to Max to set the capacity
of the LUN equal to all free space in
the cloud space.
4. Click Apply.
Utilization Info View statistics showing data uploaded,
data downloaded, and cache space
utilization for the LUN.
Click Actions, and then select
Utilization.
Recovery QTS periodically takes snapshots of a
VJBOD Cloud LUN. You can use these
recovery point snapshots to restore the
LUN to a previous state.
For details, see VJBOD Cloud Volume
and LUN Recovery .
Volume/LUN Connection Status
Status Description
Ready The cloud storage space is working normally.
Syncing A volume or LUN is currently syncing with the cloud space.
License Expiring The VJBOD Cloud license attached to this storage space will expire within
one month. You must renew it if you want to continue using volumes and
LUNs in this storage space.
License Expired The license attached to this storage space has expired. All volumes and
LUNs created in this storage space are set to read-only.
Not Ready There is a problem with the connection to this storage space.
Volume/LUN Connection Actions
To perform one of the following actions go to VJBOD Cloud > Overview , select a VJBOD Cloud volume or
LUN, click Manage, and then click Connection.
Action Description
Connect Reconnects the volume or LUN to the cloud space.
Disconnect Disconnects the volume or LUN from the cloud space. The volume or LUN becomes
read-only.
Edit Edits the volume or LUN's cloud space connection details.
QTS 4.4.x User Guide
Storage & Snapshots 174
