Daktronics OmniSport 2000 Timing Console - Manual (Page 211)

Track Mode Menus & Settings 193
MENU-SCOREBOARD
1-SCBD ON/OFF
Section 15: Track Mode Menus and Settings
The console saves the settings and does not need to be re-configured once it is set. The quickest
way to confirm settings is press [MENU]>[3]>[2]>[ENTER]. Re-confirm the settings before each meet
by saving the printout from the previous meet.
15.1 Menu Navigation
Press [MENU] to access the Main Menu screen.
The track mode has five menus, described in following sections.
There are two methods of navigating through the
menus (refer to Section 5.1 to review). If the console is
set in the swimming or diving mode, turn the console
off and restart to select the track mode.
Refer to the OmniSport 2000 Timing Console Quick
Reference Guide, ED-13584 (Figure 196) or Appendix C
for the track menu shortcut list.
15.2 Scoreboard Menu
The Scoreboard Menu is where the operator can turn the
scoreboard output ON or OFF, set the dimming
(brightness) level for Multi-drop displays, and display
Time-of-Day on the scoreboard.
Scoreboard ON/OFF
This menu is used to toggle the scoreboard output ON/OFF.
If the setting is ON, data is sent to a scoreboard. If this setting is OFF, the scoreboard will be
blank until either the start of the next race, or the scoreboard is turned back ON in the menu.
When to use this:
 The scoreboard is displaying false information due to equipment or operator error
and needs to be blanked.
 The error is corrected and the scoreboard output can be turned back on.
Figure 196: Track Menu Navigation
From Main Menu – [1]>[1]
Main Menu screen
MENU-MAI N
1-SCBD MENU
From Main Menu – [1] or [ENTER]
SCBD I S ON
SET OFF? Y/N SCBD I S OFF
SET ON? Y/N
