User’s Manual of NS3601-24P/4S Series
376
00-03-6B Cisco phones
00-0F-E2 H3C phones
00-60-B9 Philips and NEC AG phones
00-D0-1E Pingtel phones
00-E0-75 Polycom phones
00-E0-BB 3Com phones
00-01-E3 Siemens AG phones
Voice VLAN Port Configuration:
==============================
Port Mode Security Discovery Protocol
---- -------- -------- ------------------
1 Disabled Disabled
2 Disabled Disabled
3 Disabled Disabled
4 Disabled Disabled
5 Disabled Disabled
6 Disabled Disabled
7 Disabled Disabled
8 Disabled Disabled
9 Disabled Disabled
10 Disabled Disabled
11 Disabled Disabled
12 Disabled Disabled
13 Disabled Disabled
14 Disabled Disabled
15 Disabled Disabled
16 Disabled Disabled
17 Disabled Disabled
18 Disabled Disabled
19 Disabled Disabled
20 Disabled Disabled
21 Disabled Disabled
22 Disabled Disabled
23 Disabled Disabled
24 Disabled Disabled
Voice VLAN Mode
Description:
Set or show the Voice VLAN mode.
We must disable MSTP feature before we enable Voice VLAN.
It can avoid the conflict of ingress filter.
Syntax:
Voice VLAN Mode [enable|disable]
Parameters:
enable
: Enable Voice VLAN mode.
disable
: Disable Voice VLAN mode
(default: Show flow Voice VLAN mode)
Default Setting:
disable
Example:
Enable the Voice VLAN mode.
SWITCH/>voice vlan mode enable
