IFS NS3601-24P/4S GE-DSSG-244 and 244-POE User Manual

287

SWITCH/>vlan mode portbased


VLAN Link Type

Description:

Set or show the port VLAN link type.

Syntax:

VLAN LinkType [] [untagged|tagged]


Parameters:

: Port list or 'all', default: All ports

untagged

: VLAN Link Type Tagged

tagged

: VLAN Link Type Untagged

(default: Show VLAN link type)


Default Setting:

Un-tagged

Example:

Enable tagged frame for port2

SWITCH/>vlan linktype 2 tagged


VLAN Q-in-Q Mode

Description:

Set or show the port Q-in-Q mode.


Syntax:

VLAN Qinqmode [] [disable|man|customer]


Parameters:

: Port list or 'all', default: All ports

disable

: Disable Q-in-Q VLAN Mode

man

: Q-in-Q MAN Port Mode

customer

: Q-in-Q Customer Port Mode

(default: Show VLAN QinQ Mode)

Example:

Set port2 in man port

SWITCH/>vlan qinq 2 man


VLAN Ethernet Type

Description:

Set or show out layer VLAN tag ether type in Q-in-Q VLAN mode.


Syntax:

VLAN Ethtype [] [man|dot1q]


Parameters:

: Port list or 'all', default: All ports

man

: Set out layer VLAN tag ether type : MAN

dot1q

: Set out layer VLAN tag ether type : 802.1Q

(default: Show VLAN out layer VLAN tag ether type)


Default Setting:

N/A
