IFS NS3601-24P/4S GE-DSSG-244 and 244-POE User Manual

169

TCP PSH

Specify the TCP "Push Function" (PSH) value for this ACE.
0

: TCP frames where the PSH field is set must not be able to match this entry.

1

: TCP frames where the PSH field is set must be able to match this entry.

Any

: Any value is allowed ("don't-care").

TCP ACK

Specify the TCP "Acknowledgment field significant" (ACK) value for this ACE.
0

: TCP frames where the ACK field is set must not be able to match this entry.

1

: TCP frames where the ACK field is set must be able to match this entry.

Any

: Any value is allowed ("don't-care").

TCP URG

Specify the TCP "Urgent Pointer field significant" (URG) value for this ACE.
0

: TCP frames where the URG field is set must not be able to match this entry.

1

: TCP frames where the URG field is set must be able to match this entry.

Any

: Any value is allowed ("don't-care").

„

Ethernet Type Parameters

The Ethernet Type parameters can be configured when Frame Type "Ethernet Type" is selected.

Object

Description

EtherType Filter

Specify the Ethernet type filter for this ACE.
Any

: No EtherType filter is specified (EtherType filter status is "don't-care").

Specific

: If you want to filter a specific EtherType filter with this ACE, you can

enter a specific EtherType value. A field for entering a EtherType value.

Ethernet Type Value

When "Specific" is selected for the EtherType filter, you can enter a specific
EtherType value. The allowed range is 0x600 to 0xFFFF. A frame that hits this
ACE matches this EtherType value.


Buttons

: Click to save changes.

: Click to undo any changes made locally and revert to previously saved values.

: Return to the previous page.


ACL Ports Configuration

Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame
matches a specific ACE. The settings relate to the currently selected stack unit, as reflected by the page header.
The ACL Ports Configuration screen is shown

Figure 4-10-4

.
