IFS NS3601-24P/4S GE-DSSG-244 and 244-POE User Manual
158
The page includes the following fields:
Object
Description
•
Port
The logical port for the settings contained in the same row.
•
DSCP Remarking
Mode
If the QoS remarking mode is set to enabled, it should be with this DSCP
remarking/correction function according to RFC2474 on this port.
• DSCP Queue Mapping
Configure the mapping table between the queue and its DSCP value that is used
for DSCP remarking if the DSCP value of incoming packets is not specified in
RCF2474.
Best Effort = DSCP (0)
CS1 = DSCP (8)
CS2 = DSCP (16)
CS3 = DSCP (24)
CS4 = DSCP (32)
CS5 = DSCP (40)
CS6 = DSCP (48)
CS7 = DSCP (56)
Expedite Forward = DSCP (46)
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
Voice VLAN Configuration
The Voice VLAN feature enables the voice traffic forwarding on the Voice VLAN, then the switch can classifying and scheduling to
network traffic. It is recommands there are two VLANs on a port - one for voice, one for data. Before con
switch. The IP phone should configure the vo
Configuration screen is shown
Figure 4-9-14
.
