IFS NS3601-24P/4S GE-DSSG-244 and 244-POE User Manual

26

Figure 2-8

Mounting IFS-24040 in a Rack


Step6:

Proceeds with the steps 4 and steps 5 of session 2.2.1 Desktop Installation to connect the network cabling and supply power

to the Managed Switch.

Installing the SFP transceiver

The sections describe how to plug-in an SFP transceiver into an SFP slot.
The SFP transceivers are hot-swappable. You can plug-in and out the transceiver to/from any SFP port without a need to power
down the Managed Switch. As the

Figure 2-9

.

Figure 2-9

Plug-in the SFP transceiver


Approved IFS SFP Transceivers
IFS Managed switches supports both single mode and multi mode SFP transceivers. Please refer to below chart, as well as IFS
website for latest compatible SFP modules.
