User’s Manual of NS3601-24P/4S Series

340

MST4 128
MST5 128
MST6 128
MST7 128

Example:

Set MST1 priority value in 48.

SWITCH/>stp msti priority 1 48


STP MSTI Map

Description:

Show or clear MSTP MSTI VLAN mapping configuration.

Syntax:

STP Msti Map [] [clear]

Parameters:

: STP bridge instance no (0-7, CIST=0, MSTI1=1, ...)

Clear

: Clear VID to MSTI mapping

Example:

Add MST1 priority value in 48.

SWITCH/>stp msti priority 1 48

STP MSTI Add

Description:

Add a VLAN to a MSTI.

Syntax:

STP Msti Add

Parameters:

: STP bridge instance no (0-7, CIST=0, MSTI1=1, ...)

: VLAN ID (1-4095)

Example:

Add MST1 in vlan1.

SWITCH/>stp msti add 1 1


STP Port Configuration

Description:

Show STP Port configuration.

Syntax:

STP Port Configuration []

Parameters:

: Port list or 'all'. Port zero means aggregations.

Example:

Show STP status of Port1

SWITCH/>stp port configuration 1

Port Mode AdminEdge AutoEdge restrRole restrTcn bpduGuard Point2point
---- -------- ------------------------------- -------------------------- ---------------------------------
1 Enabled Enabled Enabled Disabled Disabled Disabled Auto
