Rockwell Automation 2071-Axx Kinetix 3 Component Servo Drive Serial Host Command Reference Manual User Manual
Page 86
86
Rockwell Automation Publication 2071-RM001B-EN-P - April 2013
Appendix A
Standard Drive Parameters
Default
0x0
Applicable Operating Mode
All
Digit 3
1st Gear ratio change
Ultraware Name
1st Gear ratio change
Range
Value
Description
0x0
Enable Only on Drive
Disabled
0x1
Always Enable
Default
0x0
When Enabled
Servo-Off -> Setting
Applicable Operating Mode
Follower
Modbus Address
[Pr - 3.01]
1st Gear Ratio, Follower Counts
Ultraware Name
1st Gear Ratio Numerator
Range
1…65,535
Default
4
Units
When Enabled
Servo-Off -> Setting
Applicable Operating Mode
Follower
Modbus Address
[Pr - 3.00] (continued)
Follower
