Rockwell Automation 2071-Axx Kinetix 3 Component Servo Drive Serial Host Command Reference Manual User Manual
Page 65
Rockwell Automation Publication 2071-RM001B-EN-P - April 2013
65
Standard Drive Parameters
Appendix A
[Pr - 0.29]
Allocation of Output Signals 8
Range for all digits
0…3, where 0 is Off and 1…6 are digital outputs
Data Size
4 digits
Digit
Description
Default
0
Reserved
0x0
1
Reserved
0x0
2
Reserved
0x0
3
Reserved
0x0
When Enabled
Reserved
Applicable Operating Mode
Indexing
Modbus Address
[Pr - 0.30]
Allocation of Output Signals 9
Range for all digits
0…3, where 0 is Off and 1…6 are digital outputs
Data Size
4 digits
Digit
Description
Default
0
Reserved
0x0
1
Reserved
0x0
2
Reserved
0x0
3
Reserved
0x0
When Enabled
Reserved
Applicable Operating Mode
Indexing
Modbus Address
