Rockwell Automation 2071-Axx Kinetix 3 Component Servo Drive Serial Host Command Reference Manual User Manual
Page 63
Rockwell Automation Publication 2071-RM001B-EN-P - April 2013
63
Standard Drive Parameters
Appendix A
[Pr - 0.25]
Allocation of Output Signals 4
Range for all digits
0…3, where 0 is Off and 1…6 are digital outputs
Data Size
4 digits
Digit
Description
Default
0
In Motion (IMO)
0x0
1
In Dwell (I_DW)
0x0
2
Axis Homed (HOMC)
0x0
3
Index Select 0 Out (O_ISEL0)
0x0
When Enabled
Servo-Off -> Setting
(1)
(1) Refer to
Setting Values for Parameters [Pr - 0.22]…[Pr - 0.32] on page 66
Applicable Operating Mode
Indexing
Modbus Address
