HAPSITE Smart Plus Operating Manual
5 During the preparation period, the front panel will display the PREPARING
SYSTEM message. Depending upon the chosen default method, this screen
may show PREPARING ANALYZE or PREPARING SURVEY. This message
will occur when the methods have different temperature setpoints. See
Figure
3-2 .
Figure 3-2 Front Panel Preparing System
6 To view the preparation details’ progress, touch the Details button. See Figure
3-3 .
Figure 3-3 Details Button
