Page 449
13 - 11
IP
N 07
4-
47
2-
P1
C
HAPSITE Smart Plus Operating Manual
Figure 13-7 Transferring the Sample to a 40 mL Vial
7
Label the vial with the appropriate information.
13.2.3 Loading the Wells
This section describes the procedure for loading a sample into the well of the HSS.
1
Open the top yellow cover of the HSS to expose the sample needle assembly
and metal heater block with four sample wells.
WARNING
Be careful to avoid injury when handling hot sample
vials.
WARNING
Be careful to avoid injury when loading/unloading
samples, as the HSS metal sampling needle tip is sharp.
WARNING
Be careful to avoid injury from any broken glass.
