HAPSITE Smart Plus Operating Manual
Label Chromatogram . . . . . . . . . . . Brings up a text box to label the
chromatogram. The label can be moved with
the cursor and can be saved with the data
file.
Scan Subtract . . . . . . . . . . . . . . . . . Subtracts the current scan from the
displayed RIC plots.
Peaks gives you the following submenu:
Switch to AMDIS. . . . . . . . . . . . . . . . . . Switches to the AMDIS program. Also
accessed by Shift+F8.
Search for Peaks . . . . . . . . . . . . . . . . . Search the TIC for peaks.
Show Current Search Results. . . . . . . Displays the results of the Search for
Peaks selection.
Clear the Peaks. . . . . . . . . . . . . . . . . . . Clears the identification of peaks from
the TIC graph.
Label the Peaks . . . . . . . . . . . . . . . . . . Labels identified peaks with retention
time and area.
Change Search Parameters. . . . . . . . . Displays the peak search
parameters, enables modification of
the parameters.
Previous Search Results . . . . . . . . . . . View results from a previous search.
(Drop down menu of previously
opened data files.)
TIC Graph . . . . . . . . . . . . . . . . . . . . When checked, displays TIC window.
RIC Graph . . . . . . . . . . . . . . . . . . . . When checked, displays the RIC window.
Spectrum Scan ### . . . . . . . . . . . . When checked, displays current
Spectrum/Scan window.
Control Panel . . . . . . . . . . . . . . . . . When checked, displays the Control Panel.
Properties . . . . . . . . . . . . . . . . . . . . Allows access to the properties of the
display.
