HAPSITE Smart Plus Operating Manual
10 By touching CMPD ID, a list of identified compounds will appear. See Figure
3-37 . The CAS number, the Fit and the elapsed time for each compound will
also be displayed. This screen will also display the TIC (Total Ion Count, a
measure of response) Max, the current TIC and the time the method has been
running.
NOTE: Touching a compound on the list will display its NIOSH database
information. See Step 8 on page 3-28 .
Figure 3-37 Sample Compound ID List in Survey
11 The CMPD ID screen can also be accessed by using the arrow keys to
highlight CMPD ID and pushing OK SEL. See
Figure 3-38 .
Figure 3-38 Accessing the Compound ID Screen Using the Arrow Keys
