HAPSITE Smart Plus Operating Manual
3.8 EXIT Menu
The EXIT menu is located on the top row of the front panel. See Figure 3-101 . This
option will access Turn Off, Reboot or Standby. Turn Off will shut down the
HAPSITE’s power. Reboot will reset the microprocessor in the HAPSITE and
reload the drivers. It will also restart the operating system, the HAPSITE program
and the front panel program. The Standby option will put the system into Extended
Standby. Refer to
section 3.8.1 on page 3-63 for Extended Standby instructions.
1 Touch EXIT. Alternately, use the arrow keys to highlight EXIT and push OK
SEL. See
Figure 3-101 .
Figure 3-101 Exit Menu
2 The three exit options will be displayed on the screen. There will also be a
Cancel button. Either touch or use the arrow keys to highlight the desired
choice on the screen. If using the push buttons, push OK SEL. See
Figure
3-102 .
Figure 3-102 EXIT Selections
3 A prompt will appear to confirm the selection. For example, if Turn Off is
selected, a prompt
Do you want to shutdown the HAPSITE? will appear on
the screen. Touch Yes or select Yes and push OK SEL to continue.
