HAPSITE Smart Plus Operating Manual
Figure 11-3 Error Information Button
The order of pages that appear in Wizard mode for various collection and analysis
modes are listed in
Table 11-1 .
Development of a Method starts with a set of default components. The default
settings are extracted from the software when editing a New Method. A New
Method is also supplied with a default Method filename, which can be changed on
any page of the editor. The editor will automatically increment the default name with
each successful launch and exit of the editor, provided the resulting Method is
saved.
Both section 11.2 and section 11.3 describe and define the Method Editor
interface. It also describes all the parameters used to create a HAPSITE Method
File. A HAPSITE Method File can be deployed in numerous configurations.
However, development of the complete method is done only on the Laptop and is
then downloaded to the HAPSITE.
Table 11-1 Method Editor Page Flow
GC/MS Full
Scan
GC/MS SIM Survey Full
Scan
Survey SIM
Description Description Description Description
Startup Startup Startup Startup
Inlet Inlet Tune Tune
Tune Tune Full Scan SIM
Full Scan SIM Search Search
Search Search Data Data
Data Data Summary Summary
Summary Summary
