HAPSITE Smart Plus Operating Manual
File increment digits. . . . . . . . . . . . This parameter sets the number of digits
used in the index, starting at 000 and
incrementing up to the maximum number
provided by the index digits (in this case,
999). By default, the index is three digits, but
can be specifically changed here for this
method or for the entire system on the
System Properties >> Miscellaneous
page.
Add Date and Time . . . . . . . . . . . . . This parameter adds the date and time, in the
format yyyymmdd_hhmmss to the filename
(see
Figure 11-44
). This can be added as a
suffix, which uses an underscore before the
"yyyy" information, or as a prefix, which uses
an underscore after the "ss" information. The
format of the date and time is:
yyyy is the year the data was collected
mm is the month the data was collected
dd is the day the data was collected
hh is the hour data collection was started
mm is the minute data collection was
started
ss is the second data collection was
started.
Figure 11-44 Example of Date and Time Appended to the Filename
Add as Suffix . . . . . . . . . . . . . . . . . When selected, along with Add Date and
Time, the date and time are added to the end
of the filename. It is preceded by an
underscore.
Use default directory . . . . . . . . . . . This selection sets the Method to store all
data, collected with this Method, in the
default directory specified in the Data File
Path. When this selection is unchecked, any
valid path can be entered in the Data File
Path to specify data storage.
