HAPSITE Smart Plus Operating Manual
10.2.2 Event Log Files
Event Log Files are created automatically by the system to record system state
information, such as heating or valve changes, for future reference. These files are
created daily when running the HAPSITE using the Laptop Plus IQ software. These
files are saved in the Sensor directory Events folder (as shown in
Figure 10-14 ) as
C:\haps4\ . The events would be saved in C:\haps4\Events by specifying
this location. The location where log files are saved can be changed only by
changing the Sensor directory.
By default, log files are deleted after 30 days. To modify how long the files are
saved, open up sensor properties by right-clicking on a HAPSITE Sensor icon and
selecting Properties. It can also be modified by double-clicking on a sensor or by
selecting the menu item Tools >> Sensor Properties. Select the Data Settings
tab. The window shown in
Figure 10-14 below will appear.
Figure 10-14 Sensor Properties - Data Settings
On the Maintain Logs line of Data Settings, the number of days which the log file
will be saved may be changed. Maintain Logs can also be used to save all created
files indefinitely. If a number of days is selected, each time HAPSITE Plus IQ is run
the HAPSITE will delete files which are older than the number of days selected.
NOTE: This setting is saved in the HAPSITE Plus IQ.ini file in the HAPSITE Plus
IQ program install directory. If for any reason the HAPSITE.ini file is
reloaded or deleted, the setting will change back to the default setting of
Maintain Logs for 30 days. Log files use the naming convention:
LogYYYYMMDD.evt, where YYYY is year, MM is month, and DD is day.
