HAPSITE Smart Plus Operating Manual
Chapter 10
Saving and Managing Files
10.1 Saving Files on the HAPSITE
File types are created two ways, either by the HAPSITE software or by the analyst
when analyses are performed. The list of possible file types includes:
 Method files
 Event Log files
 Data files
 Tune files
 Report files
10.1.1 Method Files
Method files are created using the HAPSITE Plus IQ software to direct the
instrument how to collect and analyze samples. Once created and saved, a Method
file can be selected to run samples. Method files are created using the Method
Editor and saved using either to a directory on the Laptop or to the HAPSITE hard
drive.
To save a newly created method using the Method Editor, press the Save button at
the bottom of the Method Editor window. The dialog window shown in
Figure 10-1
is displayed. Notice that the default location to save a method file is to the
HAPSITE.
NOTE: Method files can be saved to the HAPSITE only if the HAPSITE is
connected to the PC. Refer to section 2.4.6, Connect Laptop (if desired),
on page 2-10 for additional information on how to connect the Laptop to
the HAPSITE.
