HAPSITE Smart Plus Operating Manual
Configure . . . . . . . . . . . . . . . . . . . . Displays control information. See Figure
15-8 .
Figure 15-8 Configure Window
Manual . . . . . . . . . . . . . . . . . . . . . . . Displays additional control information. See
Figure 15-9 .
Figure 15-9 Manual Control Window
Ion Pump Status . . . . . . . . . . . . . . . Displays the Ion Pump Status. See Figure
15-10 .
