HAPSITE Smart Plus Operating Manual
10.1.5 Data Review
Data review is used to view and analyze data files. To open files, double-click on
the Data Review icon in the System Setup window, or right-click on a HAPSITE
icon and select Data Review, or select a file from the Recent Files list in System
Setup view. The Data Review window is shown in
Figure 10-9 . Refer to Chapter 9,
Data Review for additional information on Data Review.
Figure 10-9 Data Review Recall Window
The window opens showing the data folder for the currently selected HAPSITE
Data Files, organized the same as method files. Data files are saved under
/Data/method_folder_name/ where the method_folder_name
corresponds to the folder in which the method is located. For example, if the
method called Default was used to run the analysis, the folder would be
Data/Default. To select a file to open, open a folder then click on the desired data
file to open, then click the OK button. See
Figure 10-10 , which shows a selected
data file.
NOTE: Plus IQ data files are saved with a .hps file extension at the end of the
filename.
