4 - Removal and Re-installation
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 56
Figure 4-20 - One of Eight Screws On Sides of Cover (TOP VIEW FROM FRONT)
Figure 4-21 - Plastic Fastener Plates (LEFT VIEW)
14) Locate the two screws that secure the front of the cover next to the tipper.
