5 - Adjustments
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 177
If you reached a maximum for the Tipper Motor Angle setting and the device is still not covering
embossed characters completely, increase the
Tipper Motor Time setting by steps of 1ms until the
tipper covers properly.
If you reached a minimum for the Tipper Motor Angle setting and the device is still overflashing,
decrease the
Tipper Motor Time setting by steps of 1ms until the tipper covers properly.
5.8.5 Calibrate Foil Cool Time
During the tipping cycle, the hot tipper fuser presses the foil against the card, holds for a certain amount
of time, then stops heating and cools down before it pulls the foil off the card. If the foil is not being
allowed to cool long enough, the device may malfunction. If the foil is being left to cool for too long the
device may be slow or may malfunction. A typical Foil Cool Time is 40ms. There are no specific
calibration steps for adjusting the tipper cooling time.
