5 - Adjustments
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 147
b) Enter password 1234567 and press the E button to open the second password page.
c) Enter password 7654321 to open the Configuration Editing page.
d) Scroll down in the list of settings until you find the ExitHandoffAdjustmentX setting.
e) If the XY Transport bumped into the Exit Transport, decrease the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the C button, then entering the new number
on the on-screen keypad and pressing the E button. Adjust about 10 steps at a time.
f) If the card did not push far enough into the exit ramp, increase the ExitHandoffAdjustmentX
setting by selecting the number in the list, pressing the C button, then entering the new number
on the on-screen keypad and pressing the E button. Adjust about 10 steps at a time.
g) If the card is off-center from the green roller and is too close to the front of the EC2000, increase
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the C button,
then entering the new number on the on-screen keypad and pressing the E button. Adjust about
10 steps at a time.
h) If the card is off-center from the green roller and is too close to the back of the EC2000, decrease
the ExitHandoffAdjustmentY setting by clicking the number in the list, pressing the C button,
then entering the new number on the on-screen keypad and pressing the E button. Adjust about
10 steps at a time.
i) Press the Save button to save your changes.
j) Repeat these steps from step 1 until the card clamps correctly when it exits the printer.
9) Navigate to Menu > Settings > Service > MCP Commands to open the Controller Commands
page.
10) Press the Unclamp Card button to release the card.
11) Press the Exit Eject button to eject the card into the card output hopper.
12) Press the Status button to return to the Status page.
5.4 How to Calibrate the Embosser Module
5.4.1 About Embosser Calibration
The EC2000 embosser squeezes cards between two “knuckles.” Each knuckle can be adjusted higher or
lower to make sure embossed characters are being pressed deeply enough into the card, and to make sure
the card is being squeezed evenly on both sides (see Figure 5-2).
