Press This Button Verify This Happens
2 To Hopper Hopper transport moves to (or stays at) hopper 1
1 To Hopper Hopper transport moves to (or stays at) hopper 1
Bot Cartridge Unload ,
Indenter Move
Rear (black) indent cartridge moves out of embosser toward rear of
device
Bot Cartridge Load ,
Indenter Move
Rear (black) indent cartridge moves back into embosser
Bot Cartridge Home ,
Indenter Move
Rear (black) indent cartridge moves back into (or stays in) embosser
Bot Cart to Indent
Loc.
, Indenter Move
Rear (black) indent cartridge moves between letters on embosser wheel
Bot Ribbon Advance ,
Indenter Move
Ribbon in rear (black) indent cartridge advances by about ¼”
Top Cartridge Unload ,
Indenter Move
Only if testing EC2000 with Front Indenter installed:
Front (white) indent cartridge moves out of embosser toward rear of
device
Top Cartridge Load ,
Indenter Move
Only if testing EC2000 with Front Indenter installed:
Front (white) indent cartridge moves back into embosser
Top Cartridge Home ,
Indenter Move
Only if testing EC2000 with Front Indenter installed:
Front (white) indent cartridge moves back into (or stays in) embosser
Top Cart to Indent
Loc.
, Indenter Move
Only if testing EC2000 with Front Indenter installed:
Front (white) indent cartridge moves between letters on embosser wheel
Top Ribbon Advance ,
Indenter Move
Only if testing EC2000 with Front Indenter installed:
Ribbon in front (white) indent cartridge advances by about ¼”
Roller Consume
Hopper transport’s wheels turn for a few seconds
Push To Roller Hopper transport takes a card from current hopper
Shuttle To Printer Hopper transport moves to image printer
Roll To Printer
Hopper transport’s wheels turn for a few seconds to feed card into image
printer. Press
Printer Eject button to move card through image printer.
XY Home XY Transport moves to rear left of device
XY Home X
XY Transport’s X carriage moves to the left
XY Home Y
XY Transport’s Y transport moves to the rear of the device
XY To Printer XY Transport moves to image printer
XY To Printer In
XY Transport’s X carriage moves toward image printer to engage with
card
Unclamp Card
X carriage’s card clamp rotates to unclamped position
Printer Eject Card at image printer input is ejected to image printer exit
