2 - Introduction
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 14
Press This Button Verify This Happens
Clamp Card X carriage clamps card at printer exit
Embosser Home Embosser wheel moves to first character on wheel (look for empty tines
next to the tine that is currently between the hammers)
Embosser hammers open completely (not squeezing embosser tines)
Wheel Home Embosser wheel moves to first character on wheel (look for empty tines
next to the tine that is currently between the hammers)
XY To Embosser XY Transport moves card out of printer and to embosser
CardHomeXY XY Transport moves card so its lower left corner is between embosser
tines
XY To Exit
XY Transport moves card to Exit Transport’s input rollers
Unclamp Card
X carriage’s clamp releases the card
Exit Reject Exit transport raises its bottom roller, rolls for a short period of time.
Ramp fan turns on. Card goes into Card Rejection Bin.
Exit Eject Exit Transport rolls card to exit ramp, ramp fan turns on briefly.
