2 - Introduction
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 16
Sensor Name Function
Card Edge Blocked EITHER when the embosser daisy wheel is turned such that one of the
tines blocks the sensor, OR when a card enters the area between the embosser
wheels.
Wheel Home Blocked when the small fin on top of the embosser daisy wheel points toward the
front of the device.
Top Case Blocked when the top access door is closed.
Shuttle
Exception Blocked when the hopper transport pushes far enough toward the front of the
device that it mechanically rotates to orient with the manual feed slot.
Hopper Exit Blocked when a card reaches the point where it is fully and safely loaded from a
hopper into the hopper transport.
Eject Xport Reserved for future use.
Eject Bin Reserved for future use.
Exit Just Home Reserved for future use.
RI Home Blocked when the rear indent cartridge is in the loaded position (toward the front
of the device).
FI Home Only used on devices that have the optional front indent module installed. Blocked
when the front indent cartridge is in the loaded position (toward the front of the
device).
Hopper Pull Unblocked when the card puller on the hopper transport moves in to pick up a card.
Shuttle Home Blocked when the hopper transport is parked at the rear right corner of the device.
Exception Feed Blocked when a card just enters the manual feed slot.
RI Unload Blocked when the rear indent cartridge is in the unload position (toward the rear of
the device).
FI Unload Only used on devices that have the optional front indent module installed. Blocked
when the front indent cartridge is in the unload position (toward the rear of the
device).
MP Card In Reserved for future use.
Hopper Card In Reserved for future use.
Hopper1 Empty
- Hopper7
Empty Unblocked when there is no hopper installed in the specified hopper slot.
Tipper Cam Blocked when the tipper heating element is in the up/idle position.
Tipper Grip Blocked when a card just reaches the rollers on the exit ramp.
Tipper Exit Blocked when a card just reaches the end of the exit ramp.
