3 - Preventive Maintenance
ExpressCard 2000| Instant Issuance Card Personalization System | Hardware Service Manual
Page 27
Figure 3-3 - Cleaning the Right Side of the Exit Transport (TOP VIEW FROM FRONT)
d) Feed the card partly under the exit ramp rollers and press the Exit Eject button. Hold the card
there until the rollers stop moving.
Figure 3-4 - Cleaning the Exit Ramp Rollers (TOP VIEW FROM FRONT)
5) Press the Status button to return to the Status page.
6) Re-install the tipper foil spool assembly with the original tipper foil roll, or obtain and install a new
one from the customer.
7) Re-install hoppers 1 and 2.
