Custom Capture Data Project Catalyst Enterprises, Inc.
85
Disconnect with data TA700/800 to Generate Disconnect as Target at the last
data phase.
Retry Generates Retry as Target.
Disconnect without data Generate disconnect after the last data phase.
Target Abort with data Generate Target Abort at the last data phase.
Target Abort without data Generate Target Abort after the last data phase.
Available PCI-X Exerciser Commands:
Interrupt ACK
Special Cycle
I/O Read
I/O Write
MEM Read DWORD
MEM Write
Memory Read Block (Alias)
Memory Write Block (Alias)
Configuration Read
Configuration Write
Split Completion
Memory Read Block
Memory Write Block
Dual Address I/O Read
Dual address I/O Write
Dual Address Mem Read DWORD
Dual Address Mem Write
Dual Address Mem Read Block (Alias)
Dual Address Mem Write Block (Alias)
Dual Address Mem Read Block
Dual Address Mem Write Block
Target
Target Single Data Phase
Target Disconnect at Next ADB
Target Retry
Target Abort
Target Split Response
NOP
4. Enter a TARGET ADDRESS that you would like to write to and enter the
DATA or select a Data Block to be written to that address.
32/64 bit Addressing To set 32 or 64 bit addressing mode click the enabled ellipses button at the
end of the active program line Base Address Setting dialog box shown in
Figure 80. Addressing selection applies on a line to line basis.
