Custom Capture Data Project Catalyst Enterprises, Inc.
67
Defining Event Patterns
An Event pattern defines the PCI/PCI-X bus signals, including address, data and control signals to:
• Define the data capture manipulation.
• Define events that are used for Performance Analysis and Bus
Utilization measurement.
You may define up to 8 events identified as follows:
EV1 - EV8 8 Events with identical capability.
DEFAULT NAMES EV1 - EV8 are default event names that may be changed to a user defined
descriptive name for reference in the Sequencer and Performance analysis
displays.
PCI SIGNALS All PCI bus signals are included except JTAG which is used for boundary
scan testing.
EXTERNAL The TA700 & TA850 supports 16 external signals that are all sampled and
captured in memory in synch with the PCI bus signals. Not available on
the TA800.
