Catalyst Enterprises, Inc. Easy Mode
34
Performance Analysis
Figure 22 Easy Mode Performance Analysis Dialog Box
To perform an immediate Performance Analysis:
1. Click the down arrow next to the Performance Analysis Group list box and
select one of the four available analysis groups.
2. Select the parameters for analysis from the Available Items list.
3. Select the counters mode, Reset or Accumulate and click Run.
Reset/Accumulate With Reset selected, the measurement counters are reset at the beginning
of each interval. With Accumulative selected, the measurement counters
will continue to add up.
Save Settings To save the measurement setup, first select Save to open the Save As
Dialog Box, enter a new file name to save as a *.pep file and click Save.
Click the Performance Analysis Icon on the menu bar to open the Performance
Analysis dialog box
