Catalyst Enterprises, Inc.
iv
TBI* To be Implemented
NS* Not Supported
(1) The TA850 is a functional equivalent of the TA800 built as a low profile PCI card operating on +3V only
and with the parallel port interface replaced by a 10/100 ethernet connection.
TA700/800 Series Comparison Cont.
TA700 TA700C TA700PDC TA800/850 (1)
PCI-X PCI CPCI-X CPCI PCI-X PMC PCI-X PCI
Memory Size
Standard 128K 128K 128K 128K 128K 128K 128K 128k
Optional 4M 4M 4M 4M None None NS* NS*
Timing
Minimum Clock Rate [MHz] 25 25 25 25 >1KHz >1KHz >1KHz >1KHz
Maximum Clock Rate [MHz] 100 70 100 70 66.66 66.66 133.33 66.66
Asynchronous Timing Clock MHz 664 664 664 664 None None NS* NS*
Advanced Mode
User Defined Projects Y Y Y Y Y Y Y Y
Definable Event Patterns 8 8 8 8 8 8 8 8
Protocol Errors 58 51 58 51 58 51 58 51
Miscellaneous
PCI Signals sampled (Not JTAG) ALL ALL ALL ALL ALL ALL ALL ALL
External Input Signals 16 16 16 16 16 16 TBI* TBI*
Status LEDs 5 5 4 4 2 2 5 5
