Catalyst Enterprises, Inc. Custom Capture Data Project
90
Setting Exerciser Options
You may set the exerciser options globally for all input program types or locally on the
Exerciser Programming window.
Figure 85 Exerciser Options Dialog Box
On Target Disconnect/Retry
Use Same Transaction Completes from the disconnect point on,
regardless of the number of times the target
issues a disconnect. The TA700/800 will take it
from where the target disconnect was issued and
try to complete the transaction from that point
on.
Use Next Transaction The TA700/800 will bypass all of the
transactions in the current command and will
jump to the transaction for the next command.
Master Abort on No DEVSEL#
Wait Extra Cycles TA700/800 waits for 10 extra cycles.
Per PCI Specification
To set the exerciser options, click Exerciser on the menu bar and select Options
from the dropdown list to open the exerciser dialog box as shown in Figure 85.
