Custom Capture Data Project Catalyst Enterprises, Inc.
91
Master Assert FRAME#
Regardless of GNT# Once the TA700/800 is set to become a master, it
asserts the frame and starts the transaction
regardless of the status of the GNT#.
After GNT# Asserted The TA700/800 will request the bus and start the
transaction only after the GNT# is asserted.
Master Completes Transaction at Time Out
Disabled The TA700/800 continues to complete the
transaction for however many clocks it takes
regardless of GNT# being deasserted.
Enabled The TA700/800 completes the current
transaction as soon as possible after GNT# is
deasserted.
