Special Setups Catalyst Enterprises, Inc.
167
Table 5. External Signal Color Code Assignment TA700 (PCI, PCI-X, PDC*)
* For PDC pin assignments see “External Signals” on page 241.
Signal Name Color
1 XX00 Brown
2 XX01 Red
3 XX02 Orange
4 XX03 Yellow
5 XX04 Green
6 XX05 Blue
7 XX06 Violet
8 XX07 Gray
9 XX08 White
10 XX09 Black
11 XX10 Brown
12 XX11 Red
13 XX12 Orange
14 XX13 Yellow
15 XX14 Green
16 XX15 Blue
17 * GND Violet
18 * GND Gray
19 * GND White
20 * Key Black
21 * Ext_O0 Brown
22 * Ext_O1 Red
23 * Ext_O2 Orange
24 * Ext_O3 Yellow
