Catalyst Enterprises, Inc. Launching Your TA700/800
14
Note: More than one TA700/800 may be connected via the USB bus at a time.
In such cases please be sure to select the correct one using the “Attach to
device” combo box.
1. Click OK to launch the software.
Figure 5 Analyzer Tool Bar
In the event that no LPT/USB port is found connected to the hardware, the software
will display the Hardware Not Detected message. To configure a LPT port see LPT
Port Setting on page 15.
Simulation Mode Clicking OK in this dialog box will launch the analyzer software to
operate in the simulation mode.
LPT Port Problems If your analyzer hardware is connected to an LPT port and there is power
to the analyzer, but you are still getting the message Hardware Not
Detected then see the section on LPT Port setting below.
Bi-directional Port The host system LPT port must be a Bi-directional port. See LPT Port
Setting on page 15.
Launch Problems In the event that you experience difficulties in launching your software,
please see section on LPT Port Setting.
