APPENDIX B Catalyst Enterprises, Inc.
231
Scenario 4. Board running Asynchronous Timing test.
Not Applicable since running this configuration mode is not recommended when
internal 3.3V is set to internally generated.
Scenario 5. Frequency Measurement by TA700 SW
Note: Frequency measurement is done every 4 seconds and extra current draw lasts
100 ms.
Scenario 6. FPGA Configuration Time.
Bus Speed (MHz) Power Rail
Current Draw
(Amps)
Power Consumed
(Watts)
100 5V 4.09 20.45
66 5V 3.81 19.05
33 5V 3.43 17.15
Power Rail
Current Draw
(Amps)
Power Consumed
(Watts)
5V 4.09 20.45
