Catalyst Enterprises, Inc. Easy Mode
52
Write/Read Verify
Figure 42 Write/Read Verify Dialog Box
1. Select the command type from the Command dropdown list, enter the Target
address, BE and either the data to be written or a previously defined data block
and a DMA size.
2. Click Compile & Run to perform the Read/Write verification.
3. To view the executable code as shown in Figure 43 click Compile and then to
perform the Read/Write verification click Run.
Figure 43 Write/Read Verify Compiled Program
To perform Write Read Verify select Write/Read Verify from the Exerciser
dropdown list on the menu bar. This will open the Write/Read verify dialog box.
