APPENDIX B Catalyst Enterprises, Inc.
229
Alternate Jumper Configuration
Use this if your board does not have JP16.
TA700 +3.3V Power Source selection
Bus Protocol & Speed Sensing
External Power Selection
JP2
Shunt 1-2 center to left
+3.3V from external power
supply.
Shunt 2-3 center to right +3.3V Bus Power (Default)
JP10
Shunt 1-2 Top two PCI-X 133MHz
Shunt 3-3 Below top DUT capabilities
Shunt 5-6 Next to bottom PCI-X 66MHz
Shunt 7-8 Bottom two PCI (Default)
JP1
1 +3.3VEX
2 +5VEX
3 GND
